To replace the Nokia Asha 300 housing, you need to contact a service center.
The online store strongly does not recommend making a replacement yourself. Also, we do not accept any responsibility for damage to individual parts of the phone, caused by the user or employees of service centers.
The information below is a short and incomplete description of the parsing of the Nokia Asha 300 mobile phone.
All actions regarding the repair of the phone are carried out at their own peril and risk by the contractor.
1) Apply a protective film to the Touch module.
2) Open the battery cover using the release notch.
3) Remove the battery cover.
4) Remove the two Torx + size 4 screws in the order shown.
5) Remove the four Torx + size 4 screws in the order shown. Don't use them again.
6) Using a tool, release cover B on both sides.
7) Carefully lift the top of cover B.
8) Lift the top of the cover B and pull it out in the direction shown.
9) Pull out the AV socket with tweezers.
10) Pull out the DC jack with tweezers.
11) Lift up the B2B ribbon shield with a dental instrument. Be careful not to damage yourself or nearby components.
12) Pull out the B2B ribbon shield with tweezers.
13) Open the display connector with the tool. Do not damage the connector and nearby components.
14) Use a tool to free the top of the board.
15) Lift the card up by the top and pull it out in the direction shown.
16) Push the numeric keypad off cover A and remove it.
Video (click to play).
17) Loosen the top of the display with the tool.
18) Lift up the display and remove it.
19) Stick the protective film on the display.
20) Apply a protective film to the back of the Touch module.
21) Free the speaker with a dental instrument.
22) Pull out the speaker with tweezers. Don't use it again.
23) Use tweezers to remove the speaker gasket. Don't use it again.
24) Use the tool to remove the Touch module. Start at the bottom right corner.
25) Next, from the bottom left corner.
26) Lift the Touch Module from the bottom and pull it out in the direction shown.
27) Loosen one corner of the keyboard pad and peel it off. Do not use the backing again.
28) Remove the non-contact seal with tweezers. Don't use it again.
29) Place the camera removal tool on top of the camera module and press the button on the tool to release the camera module.
30) While holding the button down, raise the tool and remove the camera module.
31) Release the connector protection.
32) Use tweezers to remove the connector protector.
33) Hook up the BT-FM protective cover with the dental instrument. Be careful not to damage nearby components.
34) Remove the protective cover of the BT-FM with tweezers. Don't use it again.
35) Hook up the protective cover BB with the dental instrument from the three sides shown. Do not damage nearby components.
36) Remove the protective cover BB with tweezers. Don't use it again.
37) Hook up the IHF speaker with the dental instrument.
38) Pull out the IHF speaker with tweezers.
39) Remove the speaker pad with tweezers. Don't use it again.
40) Nokia Asha 300 disassembly is complete.
This time our article will tell you how to disassemble a Nokia Asha 300 phone, and, besides that, also replace the damaged touch glass. A standard set of dedicated tools will help us achieve our goal. Also, you need to buy a new Nokia Asha 300 touch glass in our VsePlus online store. Armed with everything you need, you can start disassembling.
Before taking the first step in disassembly, turn off the device. We put the phone with the back side up.We open the back cover exactly as shown in the diagram. We remove the battery from the compartment.
Next, take a Phillips screwdriver and unscrew the screws located around the entire perimeter of the phone case.
Then, using a metal spatula, detach the rear panel of the device, pushing it in several places where the panel is fixed. Remove the back panel.
Following this, we take a flat screwdriver and carefully detach the screen that covers the display connector located on the main board. Then immediately snap off the display connector with a metal spatula.
After that, with the same metal spatula, very carefully lift the main board of the phone and remove it from the case.
On the top side of the board are located: system connector, display connector, camera, vibration motor, sim card reader, memory card reader, processor, flash, power controller, radio unit and battery connector.
On the back of the board are: a sensor sensor, touch pad contacts, a keyboard membrane and four LEDs.
We continue to disassemble the Nokia Asha 300 phone further. We take out the keyboard panel from the upper part of the phone case. Then we remove the display very carefully by hand.
All we have in our hands is the top panel of the phone with the touch glass. We need to remove it from this panel. To do this, take a Phillips screwdriver and unscrew the four screws that fix the frame of the touch glass to the panel.
Phone disassembly is complete. Now you can install the new Nokia Asha 300 touch glass. Carefully attach it to the front bezel by screwing the frame with four screws.
And then we install other parts that follow in the correct order during the assembly process.
Nokia Asha 300 teardown is very simple, and replacing the touchscreen or display is also easy. I want to warn you right away that you are doing at your own peril and risk, if something breaks, I am not to blame :)
Disassembly of any device starts from the back cover. It must be removed, then remove the battery, SIM card and memory card, if any. Then we unscrew the six bolts around the perimeter.
