Good afternoon.
On the occasion I bought a Sigma UC APO lens with a zoom of 70 - 210. When checking during the purchase, it turned out that the lens did not focus and the seller gave it for a little money.
At home, amateur diagnostics showed that:
The lenses are clean, free from damage or defects.
The contact of the diaphragm A is sealed with tape on the board (the tape was unsticked - the lens in position A began to correctly determine and work out the diaphragm).
The lens does not extend to the full up to the prescribed 210 mm, only up to 180 mm.
The factory paint on the screws is not damaged.
The lens has spacer rings, slightly rusty (total thickness up to 1.5 mm) - removing the rings did not give any results.
At the maximum closed aperture (f / 22), there is more or less sharpness, but at the fully open aperture everything is completely bad.
You can't see it sharply through the eyepiece, you can't focus on it.
Automation and autofocus work and even when the aperture is open, autofocus finds the best position with sharpness.

The question is - is it possible at all and how to return sharpness to the lens?

Carcass Pentax K100 super, before that there were a staff 18-55 and Granit-11.

Samples of frames (with minimum and maximum aperture) are attached.

Post has been edited Postman: 25 June 2009 - 11:44

To join an existing community, you need to go to this community and click the "Join Community" button.
Joining the community occurs automatically without the approval of the candidacy of the joining by other members of the community.

Sigmovtsy under Minolta do not make lenses with HSM as far as I know, otherwise there would be a reason to figure it out.

Video (click to play).

Well done. Respect!

From my own addition. As it seemed to me, the plastic of the case is ordinary polystyrene. At least the part where the flat contacts of the zoom position are glued exactly like him - I wanted to glue the edge with “Uranus” (butyl acetate based glue) - the body began to dissolve. Therefore, (most likely) the tooth could be carved out of polystyrene and glued in place with butyl acetate. Advantages - sits down "tightly", cannot come off, just break me. And the second - if suddenly (God forbid) the metal “tooth” comes off, then dangling inside can cause a lot of trouble (at least short-circuiting the contacts with incomprehensible consequences for the camera).

By and large, both topics should be drawn up in the form of an article and posted on the site

Well done. Respect!

By and large, both topics should be drawn up in the form of an article and posted on the site

Do not rush to post the article, I have not pulled myself up yet!
One of these days I will also disassemble Sigma.

[quot] Do not rush to post the article, I have not pulled myself up yet!
One of these days I will also disassemble Sigma. [/ Quot]
The process has begun!

Well, we are waiting for the results. If there is agreement between the authors of the topics, then I am ready to draw up the results of the experiments laid out here in the form of an article (maybe someone else will be interested)

Unfortunately, the photo with a drilled groove was not very successful, because I took it off my hands. In fact, the tooth is 2/3 lower than the edge of the surface, i.e. it is impossible to lower it into the groove flat, it must be inserted from the end. When fitting, I hardly picked it out from there.

As for the article, I am FOR, becauseservice in our country, to put it mildly - NO, and not everywhere, and the manufacturers have recently been saving on everything. Apparently, soon when buying a product, you will have to sign a paper that in the event of a breakdown of the product, I have no claims to the manufacturer.

I bought a lens. I took it without checking, it's good that it's not expensive.

Sold (so that the fagots fuck thee) assured that everything is fucking.

Autofocus turned out to be minimized. The engine whines and squeals and that's it.

Well, ok, let's open it. I want to note that I am taking apart the lens for the first time in my life, so do not swear.

... ATTENTION. first text then picture

We unscrew 4 large bolts and 5 small ones (they are not visible from this angle) indicated by the arrow. Remove the lens mount.

Next, remove the ring, there is another bolt under it.

Removing the switch strip.

We unscrew the two bolts holding the board and remove the board itself.

We remove the plate with a train, which is held by three bolts.

This plastic white gear was damaged ( photo above). The slots are licked, I restored them, because I xs where to get one.

I put everything back together, the defect has not disappeared. I had to derban again and look for what else the problem is.

I disassembled the gearbox completely and saw the sadness. The pin holding the left gear was broken off (in the second photo there is a small plastic pin next to the gearbox)

The gear dangled and did not give a good grip. Glue is not an option.

I had to make a new one. But the main problem was the thickness of this pin.

1.2 mm, it won't fit anymore, there is less backlash and makes a terrible noise when focusing. You can scare people around.

I had to drill through the gearbox to secure the pin. The pin was attached to the B-7000 glue

When reassembling, pay particular attention to the photocell.

If you put it crookedly, the lens will start to go crazy and not understand what it is doing and focus on everything in a chaotic manner.

Also, the bolt rod must be placed in the correct hole, otherwise it will jam in one position.

After all the manipulations, the lens worked like new with a pleasant sound.

Cool, informative! I repair manual glasses, the process itself and the result are a pleasure, but I have not climbed into focal glass yet)

I envy you. I like to buy “non-working” modern glass for a cheap price, usually there is a repair for a couple of minutes (insert a loop, glue a small plastic part that has fallen off, replace a gear, wash off the oil, etc.).

Once I got into the mechanical "jar", in which the focus was jammed, so in the end I could not assemble it normally - the thread of the focus is a hellish monster (about a hundred notches on both sides, such a thread does not turn out to be called), and could not combine correctly, so that the focal points match the markings and the minimum / maximum are correct.

My record holder is "kid" fifty dollars from 7d Minolta. The diaphragm is jammed, during disassembly there is a supply of rancid sunflower oil, this oil itself, scratches and dust everywhere, and a lot of fungus. I took it in 2011 for 500r, soaked it for a week in total, probably, it works now with a bang))

Here is a photo from the Internet of thread at the industrial, I had some kind of reunion (alas, at the next move I got lost somewhere, I can't show a photo of a live one).

It looked like it, only much thinner and longer at times. + the edge of the thread is not visible during disassembly, no mark is placed, and the offset is only a few degrees between adjacent installation points. Well, yes, they learn from mistakes, maybe I'll come across a similar one)

Unscrew the thread, and in the place where the thread breaks and the parts are separated - a mark directly on the thread and on the body. I did that. I put it together without any problems, I found the right place by the label)

I myself was so tormented with a 64-year-old lens) after the fall, the mechanism stuck and the focus did not spin

I was offered, I took it, there was nothing to check, the carcass was at home.

Sorry wildly, but can I find out where you are? =) I have a big sadness called Canon 24-70 2.8 lens. Dropped it long ago and put it off until better times. We need a body replacement and a diaphragm repair. Can you do that? Or do you need to do the adjustment later at the officials?

that's why I didn't bother too much, I just bought it.

Not bolts, but screws. And so a molder!

"Heat resistant repair mat"

it is heat-resistant, I solder phones and laptops on it

Recently I found one interesting specimen on Ibee - Nikon 300mm f / 4 AF-S. As the saying goes: “time has worn off the percussion mechanism”. It looks very shabby, but the optics are excellent. Autofocus does not work. According to the seller, he died smoothly. At first he began to “work poorly,” and then he completely died. The price for this device was 13,000 with delivery. Shop price for 75k.

I decided not to get involved, but now I even bite my elbows. I'm using the manual myself (300mm f / 4.5 AI-S). It was necessary to take and use it like a manual.

Question: how expensive would it be to repair such a device? I understand that it is difficult to assess, but at least approximately. What reasons could lead to such a smooth failure?

I do not repair photo equipment, I use phones and laptops.

so I am not competent to answer such questions.

This is not the first time I come across plastic gears in gearboxes and, in general, with plastic where it does not need to be, there is no gain in weight, it loses in strength, but the average person will buy new glass or take it for repairs.

The author is great, although if the wheels are not killed by "manual" focusing, then soon it will be necessary to make repairs again.

Author, what city are you from?

What prevented you from ordering parts and non-iron? If I respect the desire for poebazzo.

So it was used. But at times cheaper. Here is a toad strangling me to buy L optics for my canon for 70 thousand, when you can find one to be repaired for 5000, spend a couple of evenings with benefit, at the same time and figure out how it works inside and out.

I do not care that the technique is after repair, especially after my repair.

after I dug there, I already know for sure that everything is in order there and right now it works no worse than the new one, only the design has become a bit stronger.

It is very convenient to hammer nails with this Sigma. And the weight is large and the grip is convenient for this :)

There are three types of gluing: concave-concave, flat-convex, double-concave.

Theoretically, there can also be double-curved, but I do not know of a single optical scheme from the Soviet era, where they met.

So, we have a "conditional" gluing. The lenses are generally glued together, but not rigidly, they are movable relative to each other and we are not talking about any centering. Therefore, we need to center the gluing.

I got my hands on a Sigma 18-200 lens for Nikon mount. Symptoms:

The zoom ring rotates almost freely. In this case, no zooming occurs, and from the bowels of the lens comes a faint grinding noise and chips and dirt are poured.
The focus ring also seems to spin with no visible effect.
The mount is unscrewed, the bolts are in a bag and taped to the lens. Apparently, someone has already climbed there and despaired.
Front and rear lenses are dirty but not scratched.

Of course, I immediately thought that I would find inside the fragments of the focus drive gears, that is, the patient would not live. But I decided to take a look. It turned out that everything is not so bad.

Then I assembled the mount, wiped the glass with 99.99969% alcohol with microfiber and tested it on my semi-dead Nikon D70s. The trick works, there are no errors. It buzzes and lives. I hope the story was exciting and useful)

Thanks for the answer! The EXIF is definitely not affected by this contact, I checked - when the contact pad is removed, the information still gets the focal length into EXIF - maybe it's true, it's for the flash?

As I understand it, there are 2 more such contact pads in the sigma, but they are inside, probably there is also wear and tear and because of it it became worse to focus. It's just that I easily got to it, without disassembling the lens itself, only I took off the rubber ring and the paper tape, and I'm already a little afraid to climb in)))
I have an excellent camera focusing on the far end, but at a wide angle - somehow it does not work. If the angle is reduced from 18 to 24, then it is already normal. In general, I will think, maybe I will decide to make out. If I'm mentally ready to buy a new lens)))

it seems to me that this contact is responsible for the readings of the zooming scale, and not the focus. focusing contact on the inner ring. look at the EXIF value, where the effective focal length is written.
workshops don't want to get involved with these sigma models due to the fact that they are almost entirely made of plastic. some models even have plastic focus gears. these lenses are essentially disposable.It is risky to ensure that they work properly after repairs in the laboratory, especially if the laboratory is poorly equipped and cannot perform a complete calibration.
7-8 years is a decent period for this lens, I'm even surprised) sigma 18-200 is a glass with which you can learn to shoot while you are not confident in your abilities and finances.
if I were you, I would have saved up some money and tried to fix this glass. if possible, great. if not, buy a better glass, and this can be given to someone as a gift.
nothing can be done, a good zoom for Nikon costs about a thousand dollars. the only way to save money is to handle it.
or give up zoom altogether and buy native fixes for those focal points that you use most of all.

—–
I'll correct the answer: I now understand that you were looking at the focal value in EXIF, as I suggest. I don't understand how this happens without contact at all. Can the contacts really somehow manage the focus correction? I would fix it to check the sharpness. this one would be interesting) save the control frames before and after.

Edited at 2015-08-25 12:30 pm (UTC)
