Broken TV antenna power supply? Do not rush to the store for a new one, this master class will allow you to repair your “native” adapter with your own hands and use the saved money for more necessary things.

Visual signs of a malfunction - the LED in the power supply case either does not light up at all, or periodically goes out.

We check the resistance of the primary winding of the mains transformer with a tester by connecting the test leads of the device to the mains plug of the power supply. The measurement result should be in the range of 2.5-2.7 kOhm.

In the absence of a circuit, a break in the wire connecting the plug and the transformer is possible, but a malfunction of the transformer is more common.

Next, we check the resistance at the contacts of the antenna plug, to which the power wire is soldered - the device should show that there is no short circuit.

Unscrew the screws securing the housing cover and remove it.

Now we unscrew the self-tapping screw for securing the board and take it out. In some models of power supplies, the board is simply inserted into special grooves and its fixation with a self-tapping screw is not provided.

Checking diodes D1-D4. The resistance of serviceable diodes in the forward direction will be 450-650 Ohms, in the opposite direction - to infinity, taking into account the process of charging the electrolytic capacitor.

In our case, all the diodes turned out to be serviceable.

Now it's the turn to check the health of the voltage stabilizer microcircuit.

The purpose of the microcircuit pins (see photo): left - power output (12 V), middle - common, right - input (15-20 V).

To make the verification process more visual, I soldered a yellow wire to the output, a black wire to the common one, and a red wire to the last input.

Naturally, during the repair process, we simply connect the tester probes to these points.

We check the value of the voltage supplying the microcircuit. As you can see in the picture, this parameter is within 21 V, which is normal.

Now we check the output voltage.

Here we see that the output voltage spontaneously rises to 18 V, then.

... drops sharply to almost zero. Such jumps occur two or three times a minute, but still more often the power supply does not produce anything at all.

Note that this type of failure of an integral stabilizer is rare, usually the voltage at its output is completely absent.

This is how the already soldered stabilizer microcircuit looks like.

Its marking - 78L12 - indicates that the stabilizer is designed for a voltage of 12 V. We select instead the same or similar with a stabilization voltage of 9-12 V.
It should be borne in mind that with a supply voltage of 9 V, the amplifier will reduce the gain, and increasing the voltage above 15 V can damage the amplifier.

We insert a new microcircuit and solder it.

We check the voltage at the output of the power supply unit - the tester shows 12.1 V. The repair of the power supply unit is almost complete.

We add that if the antenna has been in operation for more than two years, it is advisable to check the electrolytic capacitor 100 μF, 25 V.
In the event of a loss of capacity by this capacitor, one or two dark horizontal stripes moving in the vertical direction will be visible on the TV screen; the image at the top of such stripes can be bent to the left.
If the capacitor is defective, then it is better to change it with a new one with an operating voltage of at least 50 V.

We collect the refurbished power supply unit. When it is connected to the network, the control LED lights up - the device is operational.

Being careful, we connect the antenna cable to the connectors of the plug and continue to use the power supply unit repaired by our own hands, while saving on the purchase of a new adapter.

A thunderstorm has passed and the signal from the over-the-air antenna has disappeared. What happened? Why is there no signal in non-analog range not in digital t2? - you ask. The answer is obvious. Thunderstorm! Lightning discharges carry a static voltage that destroys active antenna amplifiers, power supplies, digital set-top boxes t2, and sometimes the televisions themselves. Therefore, during a thunderstorm, it is recommended to turn off all devices from the 220V electrical network, and disconnect the antenna cable from the TV or T2 receiver. Ideally, of course, a lightning protection, a lightning rod with a good ground loop should be installed, but even these precautionary methods do not give a 100% guarantee against lightning striking the antenna.

Do not forget that the lightning rod should be as high as possible on the roof ridge and, accordingly, at least 1.5-2 meters above the air antenna.

Lightning protection, of course, is a good thing, but what to do if lightning still got your home.

First you need to understand what went wrong. We start by turning on the TV. If the TV turns on, it's already good, but it happens that the input receiving unit flies out. Suppose you have a t2 receiver installed that receives a digital signal from a decimeter antenna and transmits it to the TV - we also plug it into the 220v network and see if it turns on. The t2 tuner turned on, let's move on (turning on the TV and t2 set-top boxes does not guarantee that one of them has not failed the receiving unit). Next, we check the performance of the antenna power supply by the same analogy as the previous two devices. The power supply has turned on, it's already good (if it did not turn on, replace the power supply). And at the end we check the amplifier board. Further, the speech will go for those who are friends with a soldering iron, if you are not like that, then just buy and replace the antenna amplifier with the same type as you had (swa 777, 999, 9999, 3501, 2000, 7777, etc. or for any similar in its characteristics)

Consider the repair of terrestrial antennas from the repair of antenna amplifiers from the so-called "Polish antennas", using the example of an amplifier Eurosky SWA-2000 fig. 1

All amplifiers are a two-stage aperiodic amplifier based on microwave bipolar transistors, connected in a circuit with an OE. For those who are friends with a soldering iron, I think it is not necessary to tell that the amplifier has two stages with decoupling along the power circuit, etc. Let's go straight to practice - during lightning discharges, the transistor of the amplifier of the first stage and the isolation capacitor, which are shown in the figure below, most often fail.

Successful repairs. And let Zeus take his lightning away from you! )

Repair of antenna amplifiers

The repair of antenna amplifiers is usually caused by static electricity (lightning discharges) and a breakdown of the power supply (overvoltage, which rarely happens).

Antenna amplifier is damaged due to a thunderstorm.

Look at the figure with the SWA-2000 amplifier, it shows the transistors involved in amplification and protection (of little help and installed in amplifiers of the 2000 series and above). In case of lightning discharges, the transistor of the amplifier of the first stage and the isolation capacitor most often fail, see Fig.

When repairing antenna amplifiers in the first stage, it is advisable to install high-frequency transistors with an F boundary of 1.5 -2 -3 GHz and a low level of intrinsic noise - Ksh, for example, transistors KT391A-2, KT3101A-2, KT3115A-2, KT3115B-2, KT3115V- 2, the noise characteristics of most amplifier models does not deteriorate, and the use of transistors 2T3124A-2, 2T3124B-2, 2T3124V-2, KT3132A-2 reduces Ksh to 1.5 dB, which improves the parameters of the amplifier. This circumstance allows us to recommend replacing the first transistor of the amplifier with those indicated by the latter, even in serviceable, but "noisy" amplifiers in order to improve the quality of their work.In the second stage, you can use cheaper and more powerful transistors KT391A-2, KT3101A-2 and even the series KT371, KT372, KT382, KT399, KT316 and others with a cutoff frequency of about 2 GHz.

If there are difficulties in repairing, in acquiring such transistors, then you can put the widespread KT399, KT316 in the first and second cascades, while there will be no noticeable deterioration of the picture.

It is better to install new transistors on the opposite side of the board, pre-drilling holes for the terminals with a drill with a diameter of 0.5 ... 0.8 mm. It is better to drill so that the hole touches the edge of the platform.

In SWA amplifiers, both transistors operate with a collector current of 10 ... 12 mA. Such a current is acceptable for the second transistor, but constantly exceeds the allowable one for the first, if transistors of the KT3115, KT3124 and KT3132A-2 series are installed. Therefore, after mounting a specific instance, it is necessary to set the operating point of the transistor VT1. To do this, the microresistor R1 is evaporated and instead of it, a trimmer resistor with a resistance of 68 ... 100 kOhm is temporarily connected. Before turning on the power, the resistor slider must be in the position of maximum resistance so as not to damage the transistor. The amplifier is supplied with a voltage of 12 V from the power supply and the voltage drop across the resistor R2 is measured. By dividing the measured voltage by the resistance of the resistor R2, the collector current is found. By adjusting the resistance of the trimmer downward, a collector current of about 5 mA is achieved, which corresponds to a minimum of noise in the characteristics of transistors. Further, instead of a trimming resistor, a constant of the same resistance is soldered.

After that, the printed circuit board and transistors are coated with a layer of radio-technical varnish or a compound to protect it from moisture.

How to avoid such breakdowns, read the article "Why did the antenna amplifier burn out?"
